S/N

Item

Parameters

1

Center Frequency(F0)

6000MHz

2

Pass Band Frequency

4000 ~ 8000MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.7dB

5

Pass Band VSWR

≤1.6:1

6

Stop Band Attenuation

≥60dB @ DC ~ 3400MHz

≥60dB @ 8700 ~ 11000MHz

7

Impedance

50 Ohms

8

Power

5.0W Max.

9

Connectors

SMA- Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
