S/N

Item

Parameters

1

Center Frequency(F0)

10MHz

2

Pass Band Frequency

9.0 ~ 11MHz

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.5:1

5

Stop Band Rejection

≥80dB @ 20 ~ 30MHz

6

Impedance

50 Ohms

7

Power Handling

+15dBm Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃
