S/N

Item

Parameters

1

Center Frequency(F0)

9.75GHz

2

Pass Band Frequency

9.0 ~ 10.5GHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Attenuation

≥40dB @ DC ~ 8.5GHz

≥40dB @ 11 ~ 23GHz

6

Impedance

50 Ohms

7

Power Handling

5W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Material

Housing: H62 Copper alloy

Cover: H62 Copper alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

80*16*9mm

13

Net weight

TBD
