S/N

Item

Parameters

1

Center Frequency(F0)

4.35GHz

2

Pass Band Frequency

3.9 ~ 4.8GHz

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥30dB @ DC ~ 3.8GHz

≥30dB @ 5.0 ~ 6.0GHz

6

Impedance

50 Ohms

7

Power

5W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-20℃ ~ +60℃

11

Material

Housing: H62 Copper alloy

Cover: H62 Copper alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

150*20*15.5mm

13

Net weight

TBD
