| Technical Data Sheet | |||
| S/N | Item | Parameters | |
| RX | TX | ||
| 1 | Center Frequency(F0) | 2470MHz | 2510MHz |
| 2 | Pass Band Frequency | 2460 ~ 2480MHz | 2500~ 2520MHz |
| 3 | Pass Band Insertion Loss | ≤1.0dB | ≤1.0dB |
| 4 | VSWR | ≤1.50:1 | ≤1.50:1 |
| 5 | Ports Isolation | ≥30dB @2500~ 2520MHz | ≥30dB @2460 ~ 2480MHz |
| 6 | Average Power | 10W Max. | 200W Max. |
| 7 | Impedance | 50 Ohms | |
| 8 | Connectors | N-Female | |
| 9 | Surface Finish | Painted Black | |
