S/N

Item

Parameters

1

Center Frequency(F0)

10.8GHz

2

Pass Band Frequency

9.8 ~ 11.8GHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band VSWR

≤1.3:1

6

Stop Band Attenuation

≥45dB @ DC ~ 9.0GHz

≥45dB @ 12.6 ~ 22GHz

7

Impedance

50 Ohms

8

Power Handling

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃

12

Material

Housing: H62 Copper alloy

Cover: H62 Copper alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

13

Dimensions

80*16*9mm

14

Net weight

0.0781 KG
