S/N

Item

Parameters

1

Center Frequency(F0)

875MHz

2

Pass Band Frequency

870 ~ 880MHz

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥45dB @ DC ~ 855MHz

≥45dB @ 895 ~ 2700MHz

6

Impedance

50 Ohms

7

Power

10W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-20℃ ~ +60℃

11

Material

Housing: 6061 Aluminum alloy

Cover: 6061 Aluminum alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

164*43*30mm

13

Net weight

TBD
