S/N

Item

Parameters

1

Center Frequency(F0)

932MHz

2

Pass Band Frequency

930 ~ 934MHz

3

Pass Band Insertion Loss

≤2.7dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥80dB @ F0±20MHz (DC ~ 912MHz , 952-1500MHz)

6

Impedance

50 Ohms

7

Power Handling

20W Max

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

0℃ ~ +40℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

164*52*34mm

13

Net weight

TBD
