Serial

Parameters

1

Cut Off Frequency

10GHz

2

Pass Band Frequency

10～24GHz

3

Pass Band Insertion Loss

≤2.0dB @ 10～10.5GHz

≤1.0dB @ 10.5～24GHz

4

Pass Band VSWR

≤1.5:1

5

Stop Band Attenuation

≥60dB @ DC～9.17GHz

6

Impedance

50 ohms

7

Power

≤15W

8

Connectors

SMA-Female

9

Surface Finish

Guided Oxygen or Black Paint

10

Temperature Range

-55℃～+85℃
