S/N

Item

Parameters

1

Cut Off Frequency

11GHz

2

Pass Band Frequency

11 ~ 40GHz

3

Pass Band Insertion Loss

≤2.0dB @ 11 ~ 11.8GHz

≤1.0dB @ 11.8 ~ 40GHz

4

Pass Band VSWR

≤1.6:1

5

Stop Band Attenuation

≥50dB @ DC ~ 9.7GHz

6

Impedance

50 Ohms

7

Power Handling

15W Max.

8

Connectors

2.92mm(K)-Female

9

Surface Finish

Guide Oxygen or Painted Black

10

Temperature Range

-55℃ ~ +85℃
