Technical Data Sheet
●	Center Frequency(F0)	380MHz
●	Pass Band Frequency	370 ~ 390MHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band Ripple	≤0.5dB
●	Pass Band Return Loss	≥23dB
●	Stop Band Rejection	≥60dB @ DC ~ 340MHz	≥60dB @ 420 ~ 1560MHz
●	Impedance	50 Ohms
●	Power Handling	20W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
