Technical Data Sheet
●	Center Frequency(F0)	2325MHz
●	Pass Band Frequency	2300 ~ 2350MHz
●	Pass Band Insertion Loss	≤1.2dB
●	Pass Band Ripple	≤0.6dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥50dB @ DC ~ 2270MHz	≥50dB @ 2380 ~ 5000MHz
●	Impedance	50 Ohms
●	Power Handling	20W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
