Technical Data Sheet
●	Center Frequency(F0)	902MHz
●	Pass Band Frequency	889 ~ 915MHz
●	Pass Band Insertion Loss	≤2.8dB
●	Pass Band Ripple	≤2.0dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥30dB @ DC ~ 885MHz	≥30dB @ 919 ~ 2500MHz
●	Impedance	50 Ohms
●	Power Handling	20W Max.
●	Connectors	N-Female
●	Surface Finish	Painted Black
●	Temperature Range	0℃ ~ +50℃
Test Curve
