S/N

Item

Parameters

1

Center Frequency(F0)

1.95GHz

2

Pass Band Frequency

1.4 ~ 2.5GHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.8dB

5

Pass Band Return Loss

≥14dB

6

Stop Band Rejection

≥50dB @ DC ~ 1.15GHz

≥30dB @ 1.15 ~ 1.25GHz

≥30dB @ 2.65 ~ 2.75GHz

≥50dB @ 2.75 ~ 5.0GHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
