S/N

Item

Parameters

1

Center Frequency(F0)

1030MHz

2

3.0dB Bandwidth

20MHz (1020 ~ 1040MHz)

3

Insertion Loss @ F0

≤1.5dB @ 1030MHz

4

Return Loss

≥20dB @ 1026 ~ 1034MHz

5

Stop Band Rejection

≥50dB @ DC ~ 970MHz

≥50dB @ 1090 ~ 3000MHz

6

Impedance

50 Ohms

7

Power

30W CW

8

Connectors

N-Male / N-Female

9

Surface Finish

Painted Black

10

Temperature Range

-10℃ ~ +50℃
