| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 942.5MHz | |
| ● | Pass Band Frequency | 925 ~ 960MHz | |
| ● | Pass Band Insertion Loss | ≤1.2dB | |
| ● | Pass Band Ripple | ≤0.6dB | |
| ● | Pass Band VSWR | ≤1.22:1 | |
| ● | Stop Band Attenuation | ≥40dB @ DC ~ 905MHz | ≥40dB @ 980 ~ 2000MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 100W Max. | |
| ● | Connectors | N-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
