Serial

Parameters

1

Center Frequency (F0)

6.0GHz

2

Pass Band Frequency

5.0～7.0GHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤1.0dB

5

Pass Band VSWR

≤1.5:1

6

Stop Band Attenuation

≥40dB @ DC～4.5GHz

≥40dB @ 7.5～10GHz

7

Impedance

50 ohms

8

Power Handling

≤2W

9

Connectors

SMA-Female

10

Surface Finish

Black Paint

11

Temperature Range

-30℃～+70℃

12

Net Weight

0.035 KG

13

Configuration

As Below (Size Unit: mm)
