| Technical Data Sheet | |||
| ● | Parameters | CH1 | CH2 |
| ● | Center Frequency(F0) | 1900MHz | 2017.5MHz |
| ● | Pass Band Frequency | 1885 ~ 1915MHz | 2010 ~ 2025MHz |
| ● | Pass Band Insertion Loss | ≤3.0dB | ≤2.0dB |
| ● | Pass Band VSWR | ≤1.40:1 | ≤1.40:1 |
| ● | Stop Band Rejection | ≥10dB @ 1860 ~ 1880MHz | ≥40dB @ 1940 ~ 1985MHz |
| ≥40dB @ DC ~ 1860MHz | ≥40dB @ 2050 ~ 4000MHz | ||
| ● | Impedance | 50 Ohms | |
| ● | Power | 50W Max. | |
| ● | Connectors | N-Male / N-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -20℃ ~ +60℃ | |
| ● | Waterproof Rating | IP65 | |
| Test Curve | |||
