| Technical Data Sheet | |||
| ● | Parameters | CH1 | CH2 |
| ● | Center Frequency(F0) | 1750MHz | 1845MHz |
| ● | Pass Band Frequency | 1735 ~ 1765MHz | 1830 ~ 1860MHz |
| ● | Pass Band Insertion Loss | ≤1.8dB | ≤1.8dB |
| ● | Pass Band VSWR | ≤1.40:1 | ≤1.40:1 |
| ● | Stop Band Rejection | ≥40dB @ DC ~ 1715MHz | ≥40dB @ 1880 ~ 3000MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 50W Max. | |
| ● | Connectors | N-Male / N-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -20℃ ~ +60℃ | |
| ● | Waterproof Rating | IP65 | |
| Test Curve | |||
