| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| ● | Center Frequency(F0) | 4800MHz | 6700MHz |
| ● | Pass Band Frequency | 4400 ~ 5200MHz | 6000~ 7400MHz |
| ● | Pass Band Insertion Loss | ≤0.7dB | ≤0.7dB |
| ● | VSWR | ≤1.50:1 | ≤1.50:1 |
| ● | Stop Band Attenuation | ≥60dB @6000~ 7400MHz | ≥40dB @ 4400 ~ 5200MHz |
| ● | Impedance | 50 Ohms | |
| ● | Average Power | 25W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Metal Color/ Painted Black | |
| ● | Temperature Range | -20℃ ~ +60℃ | |
| ● | Working Environment | Indoor | |
| Test Curve | |||
