2 way Microstrip Power Divider

  • 800-3600MHz 2 Way Power Divider
800-3600MHz 2 Way Power Divider

800-3600MHz 2 Way Power Divider

  • P/N:HXGF-G2A01-N
  • Loss:≤0.8dB
  • isolation:≥20dB
  • Connectors:N-Female
  • Product description: Small insertion loss♦Size small♦Wide frequency ♦Size can be customized♦ Are available upon request all kinds of frequency Are available upon request all kinds of frequency(The scope 1MHz-70GHz )
  • PDF technical index download

2 Way Power Divider
Specifications

Serial

Parameters

1

Way

2

2

Frequency Range

0.8~3.6GHz

3

Insertion Loss

0.8dB (Does not contain theory loss 3 dB)

4

VSWR

1.4:1

5

Isolation

20dB

6

Amplitude Balance

≤±0.3dB

7

Phase Balance

≤±3°

8

Power Handling

Forward 10Watt

9

Impedance

50 ohms

10

Surface Finish

Gush Arenaceous Guide Oxygen (Silvery White)

11

Connectors

N-Female

12

Temperature Range

-40℃~+70
