Serial

Parameters

1

Center Frequency (F0)

600MHz

2

Pass Band Frequency

597～603MHz

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥40dB @ DC～587MHz

≥40dB @ 613～1500MHz

6

Impedance

50 ohms

7

Power Handling

≤20W

8

Connectors

SMA-Female

9

Surface Finish

Black Paint

10

Temperature Range

-30℃～+60℃

11

Net Weight

TBD

12

Configuration

As Below (Size Unit: mm)
