Serial

Parameters

1

Center Frequency (F0)

2450MHz

2

Pass Band Frequency

2400～2500MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥50dB @ Fc±100MHz

(DC～2300MHz、2600～5000MHz)

6

Impedance

50 ohms

7

Power Handling

≤10W

8

Connectors

SMA-Male / SMA-Female

9

Surface Finish

Black Paint

10

Temperature Range

-30℃～+70℃

11

Net Weight

TBD

12

Configuration

As Below (Size Unit: mm)
