| Technical Data Sheet | ||
| ● | Center Frequency(F0) | 16GHz |
| ● | Pass Band Frequency | 14～18GHz |
| ● | Pass Band Insertion Loss | ≤1.4dB |
| ● | Pass Band VSWR | ≤1.8:1 |
| ● | Stop Band Attenuation | ≥40dB @ F0±5.5GHz (10. 5GHz、21.5GHz) |
| ● | Number of Sections | 7 |
| ● | Impedance | 50 ohms |
| ● | Power Handling | ≤2W |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | The Original Silver Color or Black Paint |
| ● | Temperature Range | -20℃～+85℃ |
| Test Curve | ||
