S/N

Item

Parameters

1

Center Frequency(F0)

8250MHz

2

Pass Band Frequency

7950 ~ 8550MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.4dB

5

Pass Band Return Loss

≥23dB

6

Stop Band Rejection

≥80dB @ DC ~ 7400MHz

≥50dB @ 7400 ~ 7650MHz

≥50dB @ 8850 ~ 9100MHz

≥80dB @ 9100 ~ 21000MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
