S/N

Item

Parameters

1

Center Frequency(F0)

6750MHz

2

Pass Band Frequency

6000 ~ 7500MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.9dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 5450MHz

≥50dB @ 5450 ~ 5700MHz

≥50dB @ 7800 ~ 7950MHz

≥80dB @ 7950 ~ 16000MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black
