S/N

Item

Parameters

CH1

CH2

1

Center Frequency(F0)

5395MHz

5800MHz

2

Pass Band Frequency

5320 ~ 5470MHz

5725 ~ 5875MHz

3

Pass Band Insertion Loss

≤2.0dB

≤2.0dB

4

Pass Band Ripple

≤1.3dB

≤1.3dB

5

Pass Band Return Loss

≥18dB

≥18dB

6

Stop Band Rejection

≥20dB @ DC ~ 5300MHz , 5490 ~ 5705MHz , 5895 ~ 8000MHz

7

Impedance

50 Ohms

8

Power

10W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black
