S/N

Item

Parameters

1

Center Frequency(F0)

460MHz

2

Pass Band Frequency

458 ~ 462MHz

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥60dB @ DC ~ 443MHz

≥60dB @ 477 ~ 1000MHz

6

Impedance

50 Ohms

7

Power Handling

30W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Dimensions

150*90*35mm
