S/N

Item

Parameters

1

Center Frequency(F0)

5500MHz

2

Pass Band Frequency

5000 ~ 6000MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.8dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 4730MHz

≥50dB @ 4730 ~ 4810MHz

≥50dB @ 6180 ~ 6240MHz

≥80dB @ 6240 ~ 16500MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black
