S/N

Item

Parameters

1

Center Frequency(F0)

1725MHz

2

Pass Band Frequency

1350 ~ 2100MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.45dB

5

Pass Band Return Loss

≥15dB

6

Stop Band Rejection

≥60dB @ DC ~ 1150MHz

≥60dB @ 2300 ~ 4000MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
