S/N

Item

Parameters

1

Center Frequency(F0)

6450MHz

2

Pass Band Bandwidth

2500MHz (5200 ~ 7700MHz)

3

Pass Band Insertion Loss

≤1.3dB

4

Pass Band Ripple

≤0.7dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 4500MHz

≥30dB @ 4500 ~ 4930MHz

≥20dB @ 4930 ~ 5000MHz

≥40dB @ 7900 ~ 8080MHz

≥80dB @ 8080 ~ 15000MHz

7

Impedance

50 Ohms

8

Power Handling

5.0W Max.

9

Connectors

SMA-Female
