S/N

Item

Parameters

1

Center Frequency(F0)

530MHz

2

3.0dB Bandwidth

≤3.0MHz (≤528.5 ~ 531.5MHz)

3

Insertion Loss @ F0

≤2.3dB @ 530MHz

4

Pass Band Return Loss

≥20dB @ 529.5 ~ 530.5MHz

5

Stop Band Attenuation

≥30dB @ DC ~ 523.5MHz

≥30dB @ 536.5 ~ 2000MHz

6

Impedance

50 Ohms

7

Power Handling

20W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-10℃ ~ +50℃
