S/N

Item

Parameters

1

Center Frequency(F0)

5150MHz

2

Pass Band Frequency

4600 ~ 5700MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.88dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥80dB @ DC ~ 4230MHz

≥60dB @ 4230 ~ 4350MHz

≥68dB @ 5950 ~ 6000MHz

≥80dB @ 6000 ~ 17000MHz

7

Impedance

50 Ohms

8

Power Handling

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
