S/N

Item

Parameters

1

Center Frequency(F0)

626MHz

2

Pass Band Frequency

620 ~ 632MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥30dB @ DC ~ 614MHz

≥30dB @ 638 ~ 2000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
