S/N

Item

Parameters

1

Center Frequency(F0)

1900MHz

2

Pass Band Frequency

1850 ~ 1950MHz

3

Pass Band Insertion Loss

≤1.3dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥70dB @ DC ~ 1750MHz

≥70dB @ 2050 ~ 4000MHz

7

Impedance

50 Ohms

8

Power

100W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
