S/N

Item

Parameters

1

Center Frequency(F0)

4700MHz

2

Pass Band Frequency

4400 ~ 5000MHz

3

Pass Band Insertion Loss

≤1.4dB

4

Pass Band Ripple

≤0.8dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥70dB @ DC ~ 4200MHz

≥70dB @ 5200 ~ 14500MHz

7

Impedance

50 Ohms

8

Power

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black
