S/N

Item

Parameters

1

Center Frequency(F0)

680.5MHz

2

Pass Band Frequency

663 ~ 698MHz

3

Pass Band Insertion Loss

≤1.2dB

4

Pass Band Ripple

≤0.6dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥40dB @ DC ~ 653MHz

≥40dB @ 708 ~ 1500MHz

7

Impedance

50 Ohms

8

Power

100W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
