S/N

Item

Parameters

1

Center Frequency(F0)

11200MHz

2

Pass Band Frequency

11125 ~ 11275MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.4dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥30dB @ DC ~ 10930MHz

≥30dB @ 11470 ~ 20000MHz

7

Impedance

50 Ohms

8

Power

10W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
