S/N

Item

Parameters

1

Center Frequency(F0)

7500MHz

2

Pass Band Frequency

7425 ~ 7575MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥50dB @ DC ~ 7225MHz

≥50dB @ 7775 ~ 20000MHz

7

Impedance

50 Ohms

8

Power Handling

10W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-20℃ ~ +60℃
