S/N

Item

Parameters

1

Center Frequency(F0)

2017.5MHz

2

Pass Band Frequency

2010 ~ 2025MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.3dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥40dB @ DC ~ 1990MHz

≥40dB @ 2045 ~ 4500MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
