S/N

Item

Parameters

1

Center Frequency(F0)

4.9GHz

2

3.0dB Bandwidth

250MHz Max. (4.775 ~ 5.025GHz Max.)

3

Pass Band Frequency

4.8 ~ 5.0GHz

4

Pass Band Insertion Loss

≤1.0dB @ 4.8 ~ 5.0GHz

5

Pass Band Ripple

≤0.4dB @ 4.8 ~ 5.0GHz

6

Pass Band VSWR

≤1.22:1 @ 4.8 ~ 5.0GHz

7

Stop Band Rejection

≥60dB @ DC ~ 4.6GHz

≥60dB @ 5.2 ~ 8.0GHz

8

Impedance

50 Ohms

9

Power

40W Max.

10

Connectors

SMA-Female

11

Surface Finish

Painted Black

12

Temperature Range

-30℃ ~ +70℃
