S/N

Item

Parameters

1

Center Frequency(F0)

434MHz

2

Pass Band Frequency

430 ~ 438MHz

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band Ripple

≤0.3dB

5

Pass Band Return Loss

≥20dB

6

Stop Band Rejection

≥50dB @ DC ~ 415MHz

≥50dB @ 453 ~ 1000MHz

7

Impedance

50 Ohms

8

Power Handling

100W Max.

9

Connectors

N-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
