S/N

Item

Parameters

1

Center Frequency(F0)

5.0GHz

2

Pass Band Frequency

4.0 ~ 6.0GHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.42dB

5

Pass Band Return Loss

≥18dB

6

Stop Band Rejection

≥50dB @ DC ~ 3.5GHz

≥80dB @ 6.5 ~ 14GHz

7

Impedance

50 Ohms

8

Power Handling

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃

12

Material

Housing: H62 Copper alloy

Cover: H62 Copper alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

13

Dimensions

90*19*13mm
