S/N

Item

Parameters

1

Center Frequency(F0)

2500MHz

2

Pass Band Frequency

2000 ~ 3000MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band VSWR

≤1.5:1

6

Stop Band Rejection

≥40dB @ DC ~ 1850MHz

≥40dB @ 3150 ~ 5000MHz

7

Impedance

50 Ohms

8

Power

5.0W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃

12

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

13

Dimensions

80*35*11mm
