S/N

Item

Parameters

1

Center Frequency(F0)

2275MHz

2

Pass Band Frequency

2250 ~ 2300MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Ripple

≤0.5dB

5

Pass Band VSWR

≤1.3:1

6

Stop Band Rejection

≥50dB @ DC ~ 2225MHz

≥50dB @ 2325 ~ 5000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female
