S/N

Item

Parameters

1

Center Frequency(F0)

1400MHz

2

Pass Band Frequency

1350 ~ 1450MHz

3

Pass Band Insertion Loss

≤0.6dB @ 1390 ~ 1410MHz

≤1.0dB @ 1350 ~ 1450MHz

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥50dB @ DC ~ 1278MHz

≥50dB @ 1559 ~ 3000MHz

6

Impedance

50 Ohms

7

Power Handling

20W Max

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

152*48*25mm

13

Net weight

TBD
