S/N

Item

Parameters

1

Center Frequency(F0)

2237.5MHz

2

Pass Band Frequency

2200 ~ 2275MHz

3

Pass Band Insertion Loss

≤1.2dB

4

Pass Band Ripple

≤0.7dB

5

Pass Band VSWR

≤1.22:1

6

Stop Band Rejection

≥35dB @ DC ~ 2185MHz

≥35dB @ 2290 ~ 5000MHz

7

Impedance

50 Ohms

8

Power Handling

20W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃
