S/N

Item

Parameters

1

Center Frequency(F0)

7.4GHz

2

Pass Band Bandwidth

±100MHz (7.3 ~ 7.5GHz)

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Flatness

≤0.8dB

5

Pass Band VSWR

≤1.3:1

6

Stop Band Rejection

≥60dB @ DC ~ 7.2GHz

≥60dB @ 7.6 ~ 14GHz

7

Impedance

50 Ohms

8

Power Handling

5W Max.

9

Connectors

SMA-Female

10

Surface Finish

Painted Black

11

Temperature Range

-30℃ ~ +70℃

12

Material

Housing: H62 Copper alloy

Cover: H62 Copper alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

13

Dimensions

136*57*15mm

14

Net weight

TBD
