S/N

Item

Parameters

1

Center Frequency(F0)

1000MHz

2

Pass Band Bandwidth

40MHz (980 ~ 1020MHz)

3

Pass Band Insertion Loss

≤1.5dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥45dB @ Fc±30MHz (DC ~ 950MHz , 1050 ~ 2500MHz)

6

Impedance

50 Ohms

7

Power Handling

20W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

169*50*30mm

13

Net weight

0.34KG
