S/N

Item

Parameters

1

Center Frequency(F0)

897.5MHz

2

Pass Band Frequency

880 ~ 915MHz

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Rejection

≥50dB @ DC ~ 860MHz

≥40dB @ 860 ~ 870MHz

≥40dB @ 925 ~ 935MHz

≥50dB @ 935 ~ 2700MHz

6

Impedance

50 Ohms

7

Power Handling

20W Max.

8

Connectors

N-Female

9

Surface Finish

Painted Black

10

Temperature Range

-30℃ ~ +70℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

120*62*41mm

13

Net weight

TBD
